Prerequisites:

  • A Microsoft Azure Account.
  • Basic knowledge on Azure CLI.
  • Basic Knowledge on Azure load balancers.

A virtual machine scale set is an Azure compute resource that is used to scale up  a set of identical virtual machines. In a case where by the demand arises for example a lot of traffic on a web server, you can distribute compute power using scale sets. You can also implement an upgrade policy whereby a certain number of virtual machines are updated in a given order while still serving up your application.

In this example, we are going to create two virtual machine scale sets, one based on a Linux VM running Ubuntu server 18.04 LTS and another based on Windows VM running Windows Server 2016.

The commands above will create a scale set with the name web server based off the Ubuntu server 18.04 LTS image with one running instance in the tiptoe-rg4 resource group and will also create the admin user and generate the ssh keys to used access the scale set VM's remotely.

When our scale set is done creating, we shall then be able to see it in the Azure portal. For this example we are going to simulate a load based on the CPU percentage  to test our scale set, remember to scale up a virtual machine scale set, we can use use different metrics according to our application needs.

The custom scale condition above represents increasing the machine count by 1 every time the average CPU load is above 70% for every two minutes and also generate instances up-to a maximum of five incase the load metric stays up.

To generate a CPU load, run the following Linux command on the first instance of the virtual machine scale set and wait for about 5 minutes.

dd if=/dev/zero of=/dev/null

The command will copy random bytes of data and throw them in the null directory infinitely thus generating a CPU spike overtime.

In the image below we can see the instances increasing according to our custom scale condition.

Part Two - Virtual Machine Scale Set on  Windows Server 2016

In this second part, we shall use the same scale condition for the scale set that we defined on our first example. I will use the portal to create this scale set but you can still use Azure CLI.

I will skip ahead to the scaling tab and set the Initial instance count to 1, with a minimum to maximum number of VMs 1 to 10. The scale out condition allows us to scale by 2 VMs every five minutes in a case the average CPU threshold is held at an average of 70% and also scale in by one VM in a case the average CPU threshold is 25%.

I will leave the upgrade policy to Manual

When my scale set is done creating, I will remote into it. VMSS are usually placed behind load balancers but that's something that I will cover in a future article.

To generate a spike in CPU performance, I will create a notepad file with the following command and then save it as a .vbs file.

While True
Wend

When the .vbs file is created, execute it N number of times where N is the number of logical processors that your CPU has. In my example I have two so I'll execute two times.

We'll then wait for 5 minutes and when I head back to the portal  at the instances blade, we shall see the number of instances increase.
